Vertical Machining Center MVC-955/1160/1370/1690Box Way

1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล

1. CNC Vertical Machining Center

CHARLES

MVC-955/1160/1370/1690Box Way

Box-type structure, P4-class spindle bearings, spindle sleeve is machined from SCM4, high rigidity, and heavy cutting. Use the world certificated Meehanite Casting, strengthen the internal ribs, and through annealing treatment to get a high stability and no deformed casting. The hardness is up to HRC 52°±3°。 Suitable for heavy cutting, and machine huge molds, high hardness workpiece, normal accuracy requirement workpiece. STANDARD ACCESSORIES Alarm light Arm type ATC Remote MPG Full enclosure Rigid tapping Spindle oil cooler Tool box with tool kits RS232 Interface Heat exchanger Coolant flushing system A.I.Contour Control Auto lubricating system Auto power off system Metal telescopic cover Cutting liquid defector Screw type chip conveyor (with tank) Level adjusting bolts and pads Spindle auto flush / air blast device Handle flush and air blast device OPTIONAL ACCESSORIES Air-conditioner Coolant ring C.T.S (coolant thrugh spindle) Tool setter Boat type chip conveyor (with tank) Rotary table Oil-water separator Spin window
